GZ4018

GZ4018

  • Saw Type:Bandsaw
  • Cutting Option:metal materials
  • Automation:Semi Automatic Hydraulic
  • Materials:Metal Bars / Tubes / Profiles
  • Material Width:200MM
  • Material Height:180MM

Manual Metal Cutting Band Saw Machine

Manual horizontal band saw machine, suitable for small-batch metal cutting and workshop processing applications.

Features:

✓ Manual operation, simple moving, easy installation.
✓ Hydraulic valve controls the down feeding speed for stable cutting performance.
✓ Adjustable cutting angle, capable of 45° angle cutting.
✓ Compact structure with convenient operation and maintenance.

Typical Applications:

Mainly designed for cutting metal bars, tubes/pipes, and structural steel materials. Suitable for round materials, rectangular materials, and angle cutting applications in metal fabrication workshops and industrial processing.

MODEL GZ4018
Cutting ability(mm) ● Φ180mm
■ W200×H180mm
Main motor power(kw) 0.75kw
Hydraulic motor power(kw) 0.04kw
Saw belt velocity(m/min) 40/60/80m/min
Saw blade size(mm) 2360×27×0.9mm
Weight(kg) 360kg
Saw belt tension manual
Dimensions(mm) 1400×700×1100mm
REQUEST A QUOTE

All machinery models are fully customizable

We offer highly flexible customization to meet your diverse needs. All machine dimensions and colors are fully customizable, and the voltage can be modified upon request. Furthermore, every unit can be tailored to align perfectly with your specific production processes.
