High Precision X3

    • Saw Type:Band Saw
    • Cutting Option: Ocean,Land,Air,Express,Express
    • Automation: China
    • Materials:ISO9001
    • Material Width:12000MM
    • Material Height:50000MM
    • ☎:+86 13698756478
    • ✉:JINFENG@gmali.com
ModelS-460HB
Capacity460 mm (18″)
460 x 460 mm (18″W x 18″H)
Bundle CuttingWidth195 to 350 mm (8″ to 14″)
Height125 to 230 mm (5″ to 9″)
Blade Speed20 to 100 m/min (65 to 330 fpm) (INVERTER)
MotorBlade Drive5.5 kW (7.5HP)
Hyd. Pump1.5 kW (2HP)
Coolant Pump0.2 kW (1/4HP)
Blade Size4670 x 41 x 1.3 mm (184″ x 1.6″ x 0.05″)
Blade TensionHydraulic
Index Length500 mm (20″)
500 mm x 9 times (20″ x 9)
Machine Weight2400 kg (5260 lb)
Floor Space (L x W)2645 x 2180 mm (104.1″ x 85.8″)
